Kubernetes Cluster Scan

A Kubernetes scan walks a cluster through seven phases — connectivity, inventory, identity, workload, network, supply chain, and posture — and produces a topology you can click through from namespace down to individual container.

Plan-gated

Kubernetes scans are available on the Pro and Enterprise plans.

What it discovers​

  • Cluster, node, and namespace inventory with labels and taints.
  • Workload posture — privileged pods, hostPath mounts, writable root filesystems, missing securityContexts.
  • RBAC analysis — excessive ClusterRoles, dangerous verbs, and subject sprawl.
  • Network policies, exposed Services, and Ingress misconfigurations.
  • Image supply chain — vulnerable images, missing signatures, mutable tags.
  • Compliance mapping to CIS Kubernetes Benchmark.

When to use it​

Run on every cluster at onboarding, then on a daily schedule. Run on demand after cluster upgrades, operator installs, or when onboarding a new workload.

Authentication modes​

Cybrium supports three ways to reach a cluster:

  1. Kubeconfig upload — paste or upload a kubeconfig with read access. Best for clusters outside your cloud integrations.
  2. Service account token — provide a ServiceAccount token with a read-only ClusterRole. Best for long-lived automation.
  3. In-cluster auth — deploy the Cybrium scan agent as a pod inside the cluster. Best for air-gapped or private-network clusters.
Requires authorisation

Scanning a cluster you do not operate requires a signed authorisation. The live connectivity test runs before the scan is queued.

Screenshot: Kubernetes authentication mode selector with connectivity test

Launch a scan​

  1. Go to Settings -> Integrations -> Kubernetes and register the cluster using one of the auth modes above.
  2. From the chat bar type k8s scan or use Scans -> New Scan -> Kubernetes and pick the cluster.
  3. Optionally scope to specific namespaces.
  4. Start the scan. The phase tracker shows all seven phases as they complete.

What findings look like​

Each finding names the offending object (namespace, kind, name), the failing control, severity, and a remediation that is often a ready-to-apply YAML patch or kubectl command. Supply-chain findings link directly to the SBOM for the affected image.

Where results appear​

  • Topology tab with a collapsible tree from cluster to node to namespace to workload.
  • Findings tab filtered by namespace, kind, and severity.
  • Compliance scorecard for CIS Kubernetes.
  • Report tab with a per-namespace summary.

Screenshot: Collapsible Kubernetes topology with workload-level findings
