Execution Timeline

The campaign detail page tells the story of a run as a single horizontal timeline. Instead of scrolling a log, operators see the campaign's arc as a chevron of phases, each phase decorated with the tactics and steps that actually executed — a shape that fits on one screen and makes hours of activity legible at a glance.

Screenshot: Chevron timeline with phase tactic pills and step findings

Chevron Phases​

Each phase is a chevron that lights up as the campaign advances: Reconnaissance, Initial Access, Execution, Persistence, Privilege Escalation, Credential Access, Discovery, Lateral Movement, Collection, Exfiltration, and Impact. Phases the planner decided to skip are rendered dim; phases the planner is currently in pulse with an animated border. Click a chevron to scroll the detail view to that phase.

Tactic Pills​

Below each chevron, tactic pills show which ATT&CK tactics ran in that phase. Pills are color-coded by outcome — green for fully succeeded, amber for partial, red for blocked, grey for skipped. Every pill has a visible boundary so they remain distinguishable against the background in both light and dark themes. Clicking a pill expands the step list for that tactic, showing the technique, the exit region that carried the traffic, the duration, and a short summary of what was learned.

Step-Level Findings​

When a step generates a finding — a CVE match, an exposed credential, a vulnerable misconfiguration — the finding appears inline beneath the step. The inline card shows the severity, the affected asset, and a one-click jump into the full finding in the Findings tab. This is where operators most often pivot from "what the engine did" to "what matters for the report."

Abort Flow​

Abort controls live in the timeline header. Abort Step halts only the running step and allows the planner to pick a different next move; Abort Campaign terminates the entire run, drains in-flight sessions, and flushes artifacts to the evidence bundle. Both actions require a confirmation with a reason, which is stored on the audit record.

Findings and Intel Tabs​

The Findings tab is a filterable table of every vulnerability the campaign surfaced. The Recon Intel tab is the campaign's knowledge graph — hosts, users, services, credentials, and the edges the planner discovered between them — and doubles as the input to follow-up campaigns.
